With the increasing demand for healthy and convenient foods, the vegetable drying industry is also developing, and the drying of vegetables is a steam generator. Since different food deactivation temperatures are different, the temperature needs to be precisely controlled when drying, and the temperature needs to be adjusted for different types of vegetables.
There are many kinds of vegetables, and the treatment process of each kind is basically similar, but because of the different types, the drying time, temperature coefficient and humidity need to be adjusted according to different categories, so the principle of appropriate drying temperature is crucial.
Xinda steam generator adopts automatic intelligent operation, after setting the temperature, the equipment automatically runs, saving labor, is a good helper in the vegetable drying industry. In addition, steam generators are used in various industries and have a broad application scenario, which is a hot development trend in the future. It can solve the problems of environmental protection, safety, energy saving, exemption from inspection and so on.
How to produce high-quality tomato sauce with a steam generator?
Tomato sauce is a kind of sauce made by concentration. Several processes are involved in the production process, and the most important one is the use of a steam generator for concentration processing. How does the steam generator work in the concentration process?
1.Characteristics Of Gas / Oil Fired Steam Generator
Fire tube structure: few breakdowns,low maintenance cost
Corrugation furance:increase heating surface and make the boiler be more efficient
High quality material:adopt seamless steel tube material, through X ray test for safety operation.
Automatic control:fully automatic water level alarm, avoid overpressure, overheating, safe and secure.
Compact design: small size, easy for moving
High efficient: 95% efficient reduce fuel cost
Burner: Italy brand burner for stable operation
Double safety: double safety
2.Five Security About Gas / Oil Steam Generator
Stop heating automatically when reaching the setting temperature
Stop heating automatically when reaching the setting pressure
The safety valve relief automatically when the pressure reached the setting pressure
Stop heating automatically when there is no water in the tank
Stop heating automatically when mechanical adjustable pressure controller reached the setting pressure.
3. Fuel Of Gas / Oil Steam Generator
This types steam generator can be classified into gas steam generator and oil steam generator. just the burner is different.The fuel can be liquefied natural gas ( LNG) ,light diesel oil, liquefied petroleum gas (LPG).
4. Technical Data of Gas / Oil Steam Generator
Boiler Model
LHS1-0.7-Y(Q)
Rated Steam Capacity
1000Kg
Heat Output
700kw
Rated Steam Pressure
0.7Mpa / 7 Bar
Heat Up Time
In 5 minutes
Power Supply
220V / 50 HZ
Water Inlet Diameter
DN40
Steam Outlet Diameter
DN50
Safety Valve Diameter
DN50*2
Discharge Valve Diameter
DN40
Efficiency
95%
Shipping Weight
3500kg
Shipping Size
3250*1150*2450mm
5. Application of Gas / Oil Steam Generator
Agro Industries
Steam generators ( boilers)are used for extraction of essential oils
Steamgenerators (boilers) are used for steam distillation process, in extraction of aromas, flavours and perfumes.
Steam generators (boilers) are used for soil sterilization in greenhouses.
Steam generators (boilers)are used for mushroom cultivation and mushroom processing, mushroom sterilization, mushroom seeds processing.
Steam generators (boilers)are used in horticulture to maintain the humidity and temperature inside the greenhouse.
Steam generators (boilers)are used for making cattle feed.
Chemical and Petrochemical Industry
Steam generators (boilers)are used in manufacturing of adhesives, solvents dyes and various other chemicals. Steam generators (boilers)are used for jacketed heating, various process applications in the chemical industry. Super heated steam for micro pulverising of carbon black particles . Steam generatos (boilers)are used in the fertilizer industry for various process heating. Steamgenerators( boilers)are used for curing rubber parts in an autoclave.
Food and Beverages
Steam generators (boilers)are used for large scale steaming of noodles.
Steam generators (boilers) for meat processing, and in fishery industry.
Steam generators (boilers)are used in Jacketted kettles for manufacturing of jams, sauce, and a variety of other food products.
Steam generators (boilers )for steam curing of dough,crust formation in bakeries.
Laundry and Dry Cleaning
Laundry and Dry Cleaning Steam generators (boilers) for washing clothes in washing machines and steam is used for steam ironing.
Concrete Blocks Curing
Ross steam generators (boilers) are used for curing of concrete cement blocks.
Dairy Industry
Steam generator (boilers) for manufacturing of ghee . Heating in spray drying for manufacturing of milk powder. For CIP cleaning and manufacturing of by products like Condensed milk, Khowa etc.
Drugs and Pharmaceuticals
Steam generator (boilers) for sterlisation and process applications in heating and manufacturing of pharmaceuticals and various drugs.
Electric Cables Industry
Steam generator (boilers) for cable manufacturing (curing).
Hotels, Hospitals
Steam generator (boilers)are extensively used for laundry and for heating cooking kettles.
Research and Development
Small steam generator (boilers) are used in R & D labs for a variety of research applications.
1.Characteristics Of Gas / OIl Fired Steam Generator
Fire tube structure: few breakdowns,low maintenance cost
Corrugation furance:increase heating surface and make the boiler be more efficient
High quality material:adopt seamless steel tube material, through X ray test for safety operation.
Automatic control:fully automatic water level alarm, avoid overpressure, overheating, safe and secure.
Compact design: small size, easy for moving
High efficient: 95% efficient reduce fuel cost
Burner: Italy brand burner for stable operation
Double safety: double safety
2.Five Security About Gas / Oil Steam Generator
Stop heating automatically when reaching the setting temperature
Stop heating automatically when reaching the setting pressure
The safety valve relief automatically when the pressure reached the setting pressure
Stop heating automatically when there is no water in the tank
Stop heating automatically when mechanical adjustable pressure controller reached the setting pressure.
3. Fuel of Gas / Oil Steam Generator
This types steam generator can be classified into gas steam generator and oil steam generator. just the burner is different.
The fuel can be liquefied natural gas ( LNG) ,light diesel oil, liquefied petroleum gas (LPG).
4. Technical Data of 100kg Gas / Oil Steam Generator
Boiler Model
LHS0.1-0.7-Y(Q)
Rated Steam Capacity
100Kg
Heat Output
72kw
Rated Steam Pressure
0.7Mpa / 7 Bar
Heat Up Time
In 5 minutes
Power Supply
220V / 50 HZ
Water Inlet Diameter
DN20
Steam Outlet Diameter
DN25
Safety Valve Diameter
DN25
Discharge Valve Diameter
DN25
Efficiency
95%
Shipping Weight
850kg
Shipping Size
1500*900*1550mm
5. Application of Gas / Oil Steam Generator
Agro Industries
Steam generators ( boilers)are used for extraction of essential oils
Steamgenerators (boilers) are used for steam distillation process, in extraction of aromas, flavours and perfumes.
Steam generators (boilers) are used for soil sterilization in greenhouses.
Steam generators (boilers)are used for mushroom cultivation and mushroom processing, mushroom sterilization, mushroom seeds processing.
Steam generators (boilers)are used in horticulture to maintain the humidity and temperature inside the greenhouse.
Steam generators (boilers)are used for making cattle feed.
Chemical and Petrochemical Industry
Steam generators (boilers)are used in manufacturing of adhesives, solvents dyes and various other chemicals.
Steam generators (boilers)are used for jacketed heating, various process applications in the chemical industry.
Super heated steam for micro pulverising of carbon black particles .
Steam generatos (boilers)are used in the fertilizer industry for various process heating.
Steamgenerators( boilers)are used for curing rubber parts in an autoclave.
Food and Beverages
Steam generators (boilers)are used for large scale steaming of noodles.
Steam generators (boilers) for meat processing, and in fishery industry.
Steam generators (boilers)are used in Jacketted kettles for manufacturing of jams, sauce, and a variety of other food products.
Steam generators (boilers )for steam curing of dough,crust formation in bakeries.
Laundry and Dry Cleaning
Laundry and Dry Cleaning Steam generators (boilers) for washing clothes in washing machines and steam is used for steam ironing.
Concrete Blocks Curing
Ross steam generators (boilers) are used for curing of concrete cement blocks.
Dairy Industry
Steam generator (boilers) for manufacturing of ghee . Heating in spray drying for manufacturing of milk powder. For CIP cleaning and manufacturing of by products like Condensed milk, Khowa etc.
Drugs and Pharmaceuticals
Steam generator (boilers) for sterlisation and process applications in heating and manufacturing of pharmaceuticals and various drugs.
Electric Cables Industry
Steam generator (boilers) for cable manufacturing (curing).
Hotels, Hospitals
Steam generator (boilers)are extensively used for laundry and for heating cooking kettles.
Research and Development
Small steam generator (boilers) are used in R & D labs for a variety of research applications.
1.Characteristics Of 50-1000KG Gas/Oil Steam Generator
The liquid crystal display screen makes the boiler running status clear, and users can control it at any time.
The Steam Generator uses a foreign-imported burner to make the operation more stable, low noise, and more energy-saving combustion.
The boiler uses well-known brand high temperature resistant water pump, compact structure, high mechanical strength and stable performance.
Xinda Boiler has multiple protection systems: overpressure protection, safety valve overpressure protection, water shortage protection, leakage protection, overheat protection, burner flameout protection, etc.
2.Parts Introduction Of 50-1000KG Gas/Oil Steam Generator
Pressure controller: double pressure protection, automatic shutdown when pressure is reached, and automatic exhaust when overpressure.
Spring-loaded safety valve: high sensitivity, automatic pressure relief when overpressure, prevent explosion accident caused by excessive pressure of the boiler, and protect the safe operation of the boiler.
High-quality water pump: All-copper core high-quality water pump, durable quality is guaranteed, you can use it more assured.
Electrical part: Safe circuit design, safer and more stable in use.
Control panel: microcomputer one-button operation, real-time display of water level pressure, simple and clear.
3.Technical Data of 50-1000KG Gas/Oil Steam Generator
Type
LSS0.05-0.4/0.7-Y/Q
LSS0.1-0.4/0.7-Y/Q
LSS0.2-0.4/0.7-Y/Q
LSS0.3-0.4/0.7-Y/Q
LSS0.5-0.4/0.7-Y/Q
LSS1.0-0.4/0.7-Y/Q
Rated Evaporation Capacity(kg/h)
50
100
200
300
500
1000
Rated Pressure(MPa)
0.4/0.7
Steam Temperature(℃)
151/171
Fuel consumption
Diesel oil(kg/h)
3.2
6.4
12.8
19.2
31.8
63.6
Coal gas(Nm3/h)
8.9
17.7
35.5
53.2
88.7
177.4
Natural gas(Nm3/h)
4.0
7.9
15.7
24.8
39.7
79.3
Liquefied gas(kg/h)
3.3
6.5
13
19.5
33
66
Size(mm)
600*1300
780*1530
860*2100
980*2380
1050*2420
1440*2990
Weight(kg)
500
600
700
800
1300
2500
4.Application of 50-1000KG Gas/Oil Steam Generator
1.Characteristics Of Gas / Oil Fired Steam Generator
Fire tube structure: few breakdowns,low maintenance cost
Corrugation furance:increase heating surface and make the boiler be more efficient
High quality material:adopt seamless steel tube material, through X ray test for safety operation.
Automatic control:fully automatic water level alarm, avoid overpressure, overheating, safe and secure.
Compact design: small size, easy for moving
High efficient: 95% efficient reduce fuel cost
Burner: Italy brand burner for stable operation
Double safety: double safety
2.Five Security About Gas / Oil Steam Generator
Stop heating automatically when reaching the setting temperature
Stop heating automatically when reaching the setting pressure
The safety valve relief automatically when the pressure reached the setting pressure
Stop heating automatically when there is no water in the tank
Stop heating automatically when mechanical adjustable pressure controller reached the setting pressure.
3. Fuel of Gas / Oil Steam Generator
This types steam generator can be classified into gas steam generator and oil steam generator. just the burner is different.The fuel can be liquefied natural gas ( LNG) ,light diesel oil, liquefied petroleum gas (LPG).
4. Technical Data of 200kg Gas / Oil Steam Generator
